Description
Large Limatherm Sensor temperature controller. It has a universal input suitable for most common thermocouple sensor as well as Pt100. Low or standard 230V power supply can be selected. Up to 3 outputs programmed as alarm or control outputs, 3 universal outputs including SSR 14V for control of three-phase semiconductor relays or 4÷20mA (control or retransmission). Two displays: upper red colour presents temperature of process; lower green colour presents set temperature. Black enclosure, anti-reflection coating and clear indication. Degree of protection of front panel IP65. There is a possibility to block the access to specified parameters via software.
Files
Catalog card
General
Compatible devices
Additional accessories
Contact form
Characteristic
- programmable temperature controller
- 4 digit dual LED display
- PID control; ON/OFF control
- auto-tuning
- sensor offset
- front panel: IP65
Specifications
- universal input: TCRTD
- output: 2xrelay
- third-purpose programmable output 4-20mA, SSR 14V
- power supply: 230V AC, 24V DC / AC ±10%
- dimensions: 96 × 96 × 92; otwór; 92,5 × 92,5 mm
